6.4.2 Return Codes
Possible error codes in Message Data word "Return Code" (The Return Codes
can be byte swapped)
Return Code Name
8010h DPMC_ERR_V1C_CLOSED
8011h DPMC_ERR_V1C_STOPPED
8012h DPMC_ERR_V1C_STARTED
8013h DPMC_ERR_V1C_STATE_UNKNOWN
8021h DPMC_ERR_V1C_REQ_ACTIVE
8022h DPMC_ERR_V1C_NOT_ALLOWED
8023h DPMC_ERR_V1C_INVALID_PAR
8024h DPMC_ERR_V1C_MEM_ALLOC
8025h DPMC_ERR_V1C_L2_REQ
8026h DPMC_ERR_V1C_TIMEOUT
8028h DPMC_ERR_V1C_INVALID_LEN
8030h DPMC_ERR_V1C_REQ_NEG
8031h DPMC_ERR_V1C_REQ_RE
8042h DPMC_ERR_V1C_REQ_WITHDRAW
8043h DPMC_ERR_V1C_REQ_NOT_FOUND
80C1h DPMC_ERR_V1C_MM_FE
80C2h DPMC_ERR_V1C_MM_NI
80C3h DPMC_ERR_V1C_MM_AD
80C4h DPMC_ERR_V1C_MM_EA
80C5h DPMC_ERR_V1C_MM_LE
80C6h DPMC_ERR_V1C_MM_RE
80C7h DPMC_ERR_V1C_MM_IP
80C8h DPMC_ERR_V1C_MM_SC
80C9h DPMC_ERR_V1C_MM_SE
80CAh DPMC_ERR_V1C_MM_NE
80CBh DPMC_ERR_V1C_MM_DI
80CCh DPMC_ERR_V1C_MM_NC
Refer to Error Codes (page 182).
ProSoft Technology, Inc.
August 12, 2014
Meaning
Internal DPMC instance no longer exists
Internal DPMC instance has already been stopped
Internal DPMC instance has already been started
Internal DPMC instance has entered an undefined
state
A request is already active
Internal DPMC module not initialized correctly
Invalid parameter in user request
Internal memory allocation error
Unknown opcode in the confirmation
Active request terminated with timeout
Invalid length in user request
Negative indication from lower layer
1
Message frame format error in response
Request was recalled
Associated request block not found
Format error in request frame
Function not implemented
Access denied
Area too large
Data block length too large
Format error in response frame
Invalid parameter
Sequence conflict
Sequence error
Area non-existent
Data incomplete or incorrect
Master parameter set not compatible
