Configuring the Module
User Manual
3 In the Edit dialog box, change the values for the selections in this section of
the configuration to match the values in the following illustration. To change a
value, select the parameter to modify in the left pane, and then type the new
value in the edit field in the right pane. If you are not sure what to enter here,
use the default values.
Note: The values you enter for the purpose of this example configuration are used by the sample
program that you will download to the processor later in this section. You may need to change
these values as you implement your production system. Use the following chapters for your
Quantum or Unity configuration software, or the online help system, for detailed information on
each of the parameters associated with the module.
