ProSoft Technology ProTalk PTQ-PDPMV1 User Manual page 173

PTQ-PDPMV1 ♦ Quantum Platform
PROFIBUS DP Master Network Interface Module for Quantum
Command and Response Layout: Set Operating Mode
Message ID
Message information
Command
Data size
Frame count
Frame number
Offset high
Offset low
Extended word 1
Extended word 2
Extended word 3
Extended word 4
Extended word 5
Extended word 6
Extended word 7
Extended word 8
Mode
40h: STOP
80h: CLEAR
C0h: OPERATE
Conf. Req.
00h: Confirmation is not required
01h: Confirmation required. All confirmations are automatically sent by the
Master; the user is not required to send a confirmation message.
Fault Information
If "Invalid Other" is returned in the Message Information word in the header of the
response, information about the fault can be found here. Refer to Return Codes
(page 181) for more information.
0100h: Invalid operating mode
FF00h: Module not initialized
ProSoft Technology, Inc.
August 12, 2014
Command
(ID)
0240h
0200h
0000h
0100h
0100h
0000h
0000h
Conf Req Req Mode
-
-
-
-
-
-
-
Response
(ID)
0200h
0200h
0000h
0100h
0100h
0000h
0000h
Conf. Req Act. mode.
-
-
-
-
-
Appl. Specific Error Code
Fault Information
Mailbox Messaging
User Manual
Set Operation Mode
Page 173 of 306
