Mailbox Messaging
User Manual
6.4.3 Error Codes
If the return code indicates DPMC_ERR_V1C_REQ_NEG, the status values
according to the DP-standard may be available in Error Code 1. Refer to the
PROFIBUS DP specification for information on how to interpret these status
values.
Error Code Name
01h L2_STATUS_UE
02h L2_STATUS_RR
03h L2_STATUS_RS
0Ch L2_STATUS_RDL
0Dh L2_STATUS_RDH
0Fh L2_STATUS_NA
Page 182 of 306
PROFIBUS DP Master Network Interface Module for Quantum
Meaning
Refer to PROFIBUS DP specification
