Mailbox Messaging
User Manual
6.2.10 Mailbox Message: Start Slave
This mailbox message starts a selection of slaves that was previously removed
from the processing cycle by means of the mailbox message
FB_APPL_STOP_SLAVE.
The message is allowed in all operation modes (STOP, CLEAR and OPERATE).
Note: The message will be accepted even if one or several slaves are not part of the configuration
and can therefore obviously not be started. The application can, however, find out about this
situation by evaluating the "Fault information" and "Message data words" of the response.
Command and Response Layout: Start Slave
Message ID
Message information
Command
Data size
Frame count
Frame number
Offset high
Offset low
Extended word 1
Extended word 2
Extended word 3
Extended word 4
Extended word 5
Extended word 6
Extended word 7
Extended word 8
Message data word 1
Message data word 2
Message data word 3 to
Message data word 63
Page 174 of 306
Command
(ID)
0240h
0B00h
7E00h
0100h
0100h
0000h
0000h
-
-
-
-
-
-
-
Slave 1 Slave 0
Slave 3 Slave 2
... ...
62
Slave 125 Slave 124
PROFIBUS DP Master Network Interface Module for Quantum
Response
(ID)
0200h
0B00h
7E00h
0100h
0100h
0000h
0000h
-
-
-
-
-
Additional Fault Information
Fault Information
Slave 1 Slave 0
Slave 3 Slave 2
... ...
Slave 125 Slave 124
PTQ-PDPMV1 ♦ Quantum Platform
Start Slave
