Mailbox Messaging
User Manual
Example: To address Group 1, 2, and 4, the Group Select value should be D0h.
If an individual slave should be addressed, the correct group selection must also
be made, as the slave will ignore the message if it does not belong to the
requested group(s).
What group(s) a slave belongs to is determined during network configuration,
and is downloaded during initialization to each slave via the PROFIBUS telegram
Set_Prm.
Control Command
This parameter specifies the command to send:
Bit
0 (LSB)
1
2
3
4
5
6
7 (MSB)
Combinations of the bits (Unsync/Sync and Unfreeze/Freeze
Bits 0 or 6
0
0
1
1
Fault Information and Extended Fault Information
"Fault Information" Contents
0100h Address out of range
0200h Group number 0 not
permitted
0A00h Failed to send Global
Control request
FE00h Command not
possible in Class 2
only mode
FF00h Module not initialized
Page 158 of 306
PROFIBUS DP Master Network Interface Module for Quantum
Explanation
Reserved, set to zero
Reserved, set to zero
Unfreeze input data
Freeze input data
Unsynchronize output data
Synchronize output data
Reserved, set to zero
Reserved, set to zero
Bits 1 or 7 Explanation
0 No function
1 Function will be activated
0 Function will be inactive
1 Function will be inactive
"Extended Fault Information" Contents
-
-
0A00h
0150h
0250h
0350h
0450h
-
-
PTQ-PDPMV1 ♦ Quantum Platform
Incorrect operation mode (CLEAR/OPERATE
only)
Invalid Freeze Group (Group is not initiated to be
Freeze Group)
Invalid Sync Group (Group is not initiated to be
Sync Group)
Incorrect Control Command
No Sync -/ or Freeze groups enabled in Master
configuration
