The actual variable name will depend on the module name configured by the
user at PCB. These data type names are considering the default module name
(PTQPDPMV1).

4.11.3 Trigger Register

The mailbox requests are initiated by the "trigger" register (INT) that is defined as
an input/output pin. The mailbox request is initiated after the application moves a
value of 1 to the trigger register.
The current value of all mailbox triggers for your application must be equal to 0 in
order to perform a mailbox request. If you are using more than one mailbox
function block, you must add program code to guarantee that this condition is
satisfied. Therefore, a mailbox function block is only allowed to send a new
mailbox request after the processor receives confirmation that the previous
mailbox request was acknowledged by the module. This condition is determined
by checking the status of all trigger registers (0=OK). It also prevents an attempt
to send more than one mailbox request in a single PLC scan.
The following table shows the trigger registers used for each mailbox function
block:
File Name
ACCREAD.ASC
ACCWRITE.ASC
GETALARM.ASC
GETCFG.ASC
GETDIAGN.ASC
GETLIVE.ASC
SETADDRS.ASC
SETOPMD.ASC
SETSLVMD.ASC
SETSLVS.ASC
ColdBT.ASC
ProSoft Technology, Inc.
August 12, 2014
Description
Acyclic Read Mailbox
Acyclic Write Mailbox
Alarm Mailbox
Get Configuration Mailbox
Get Diagnostics Mailbox
Get Live List Mailbox
Set Slave Address Mailbox
Set Operating Mode Mailbox
Set Slave Mode Mailbox
Start/Stop Slaves Dynamically
Remote Coldboot from PLC
Configuring the Processor with Concept 2.6
Trigger
AcRead
AcWrite
-
GetCnfg
GetDiag
GetList
SetAddr
SetOper, SetStop, SetClear
SetMdSlv
Start, Stop
Cldboot
