9.1.3 Hardware Specifications
Specification
Backplane Current Load
Operating Temperature
Storage Temperature
Relative Humidity
Vibration
Shock
Dimensions (HxWxD), Approx.
LED Indicators
Debug/Configuration Ports
Configuration Serial Port (PRT1)
Configuration Ethernet Port
Application Port
PROFIBUS Master Port
Page 246 of 306
PROFIBUS DP Master Network Interface Module for Quantum
Value
1100 mA maximum @ 5 Vdc ± 5%
0°C to 60°C (32°F to 140°F)
-40°C to 85°C (-40°F to 185°F)
5% to 95% (with no condensation)
Sine vibration 4-100 Hz in each of the 3
orthogonal axes
30 g, 11 mSec. in each of the 3 orthogonal axes
250 x 103.85 x 40.34 mm
9.84 x 4.09 x 1.59 in
Module Status
Backplane Transfer Status
Serial Port Activity LED
Serial Activity and Error LED Status
Master Status Operations
Network Drop Communication
Master Token-Hold
Master database configuration
DB-9M PC Compatible
RS-232 only
No hardware handshaking
RJ45 Connector
Link and Activity LED indicators
DB-9F Optically Isolated RS-485
Ready, Run, Error and Token LED Indicators
