Reference
User Manual
Word Name
Offset
42 PROFIBUS Master Module
Status
43 to 44 PROFIBUS Configuration
Checksum
45 to 46 PTQ Module Configuration
Checksum
47 Application Program Scan
Counter
48 Module PROFIBUS Output
Image Data Update Counter
49 Module PROFIBUS Input Image
Data Update Counter
50 Module Out Mailbox Counter
51 Module In Mailbox Counter
52 Module Alarm IND Receive
Counter
53 Module Alarm CON Receive
Counter
54 Cyclic Input Data Start Offset
55 Cyclic Output Data Start Offset
56 Module Backplane Read Count
57 Module Backplane Write Count
58 Module Backplane Error Count
Page 258 of 306
PROFIBUS DP Master Network Interface Module for Quantum
Description
Represents the PROFIBUS Master module's operating status
Bit 2=Application status
0 - Application stopped
1 - Application running
Bit 8=Data exchange (FBRS)
0 - There is no data exchange with any of the assigned slaves
1 - There is data exchange with at least one of the assigned slaves
Bit 9=Slave input frozen/cleared (FBFC)
0 - A slave's inputs in the IN area are cleared if a slave is not in Data
Exchange
1 - A slave's inputs in the IN area are frozen if a slave is not in Data
Exchange
Bit 12=Reset (RDR)
0 - No action
1 - A reset is requested by the PROFIBUS Master module because a new
database has been downloaded
CRC32 checksum for PROFIBUS Master configuration downloaded from
configuration utility
PTQ-PDPMV1 module configuration checksum for module configuration
downloaded from configuration utility
PTQ-PDPMV1 module program scan counter. Can be used to gauge
application code scan time performance
Counter representing the number of times the output data image is
transferred to the module's internal Master
Counter representing the number of times the input data image is
transferred from the module's internal Master
Incremented at every mailbox requested from the module
Incremented at every mailbox response sent to the Quantum
Number of spontaneous alarm messages received from slave
Number of confirmation messages received from slaves indicating that the
slave received the confirmation message from the PTQ-PDPMV1 module
Cyclic input data start offset
Cyclic output data start offset
Rollover counter of the number of PTQ-to-processor backplane read data
transfers
Rollover counter of the number of PTQ-to-processor backplane write data
transfers
Rollover counter of the number of PTQ-to-processor backplane data
transfers that have failed
