Configuring the Processor with Concept 2.6
User Manual
7 Select O
BJECTS
SETOPMD function block. Click at the C
8 Insert the SETOPMD function block in the MAINPTQ section.
Associate the variables required for the input and output pins for this function
block.
IMPORTANT: The following pins must be associated to the variables previously imported. The
user cannot associate these pins to any other variables. This important step must be followed for
all function blocks.
PIN
StatOut
MailOut
StatIn
MailIn
Page 122 of 306
-FFB S
ELECTION
Type Default Variable Name
Input/output PTQPDPMV1_Out_Stat
Input/output PTQPDPMV1_Out_Mail
Input PTQPDPMV1_In_Stat
Input PTQPDPMV1_In_Mail
PROFIBUS DP Master Network Interface Module for Quantum
. Click the DFB button and select the
button to confirm.
LOSE
1
Data Type
PTQ_OUT_STATUS
PTQ_OUT_MAILBOX
PTQ_IN_STATUS
PTQ_IN_MAILBOX
