1.1

Hardware and Software Requirements

1.1.1 Quantum Hardware

This guide assumes that you are familiar with the installation and setup of the
Quantum hardware. The following should be installed, configured, and powered
up before you proceed:

Quantum processor

Quantum rack

Quantum power supply

Quantum Modbus Plus Network Option Module (NOM Module) (optional)

Quantum to PC programming hardware

NOM Ethernet or serial connection to PC

1.1.2 PC and PC Software

ProSoft Technology recommends the following minimum hardware to use the
module:

Windows PC with 80486 based processor (Pentium preferred) with at least
one COM, USB, or Ethernet port

1 megabyte of system memory
 Unity™ Pro PLC programming software, version 3.0 or later
or
Concept™ PLC programming software, version 2.6 or later
or
Other Quantum Programming Software
Note: ProTalk module configuration files are compatible with common Quantum programming
applications, including Unity Pro and Concept. For all other programming applications, please
contact technical support.
