Calculated Times for Detecting a Missing Counterpart
Baud Rate
12 Mbps T
= 50 ms, T
TR
1.5 Mbps T
= 186 ms, T
TR
500 kbps  T
TR
93.75 kbps (PA)  T
45.45 kbps (PA)  T
9.6 kbps  T
= 23200 ms, T
TR
Ping Sequence
This section shows the ping sequence, and how the COM-bit in register "HSBY
Remote status" is affected under different scenarios.
The figures show the active and the remote (passive) Masters connected via the
PROFIBUS network. For each Master, the DPRAM (that is, application interface)
and the software objects that are responsible for the ping sequence are shown.
Start-up
Local (active) Master operational prior to passive
As soon as the local (active) Master is ready to communicate on the PROFIBUS
network, it would start polling for ping messages from the passive one. As soon
as it receives the first ping request, the COM-bit is altered from zero to one.
