Configuring The Processor With Concept - ProSoft Technology ProTalk PTQ-PDPMV1 User Manual

PTQ-PDPMV1 ♦ Quantum Platform
PROFIBUS DP Master Network Interface Module for Quantum
4

Configuring the Processor with Concept 2.6

In This Chapter

Overview ............................................................................................. 102

Before You Begin ................................................................................ 103

Information for Concept Version 2.6 Users.......................................... 104

Step 1: Exporting the Files from PCB .................................................. 106

Step 2: Converting the Function Blocks............................................... 109

Step 3: Setting up the Concept Project ............................................... 113

Step 4: Importing the Variables ........................................................... 116

Step 5: Creating the Function Block Instances .................................... 119

Step 6: Downloading the Concept Project ........................................... 126

Using the Concept Project ................................................................... 127

Using Mailbox Function Blocks ............................................................ 130

Mailbox Overview ................................................................................ 136
Important: The following steps are for Concept version 2.6 or newer. Earlier versions of Concept
are not supported.
HSBY Note: Concept software does not support 140CPU67160 processor and therefore does
not support the PTQ-PDPMV1 HSBY functions.
Important Note: Concept software does not report whether the PTQ module is present in the rack,
and therefore is not able to report the health status of the module when the module is online with
the Quantum processor. Please consider this when monitoring the status of the PTQ module.
ProSoft Technology, Inc.
August 12, 2014
Configuring the Processor with Concept 2.6
Page 101 of 306
User Manual
