Configuring the Module
User Manual
2 On the shortcut menu, select C
Choose Module Type dialog box.
HSBY Note: For Hot Standby support, select the Enable "Hot Standby" checkbox.
3 In the Product Line Filter area of the dialog box, select PTQ. In the Select
Module Type dropdown list, select PTQ-PDPMV1, and then click OK to save
your settings and return to the ProSoft Configuration Builder window.
The next task is to set the module parameters.
Page 24 of 306
PROFIBUS DP Master Network Interface Module for Quantum
M T
HOOSE ODULE YPE
PTQ-PDPMV1 ♦ Quantum Platform
. This action opens the
