Connector Specifications

Optical Transceiver Interface Module Specification

Version 1.0
Refer to the following table for information about the connector specifications for the
Acme Packet 4500.
Specification
RJ45/Management Ethernet
Ports
RJ45/Alarm Contact Port
RS232/Serial Port
GigE Port(s)
IEC Connector Ports
Terminal Block Connections
Refer to the following table for information about the optical specifications of the
GigE SFP optical transceivers for the Acme Packet 4500.
Specification Multimode (SX) Fiber Module
Wavelength λ 850 nm
Laser Type VCSEL
Fiber type / -0.5 to 550m -50μm
Transmission Distance -0.5 to 550m -50μm
Description
The 3 x 8-pin RJ45 10/100/1000BaseT Gigabit Ethernet ports
are compliant with IEEE's 802.3, 802.3u, and 802.3ab.
Any alarms generated by the system are accessible via the 8-pin
RJ45 alarm contact port.
The RS232 serial port uses an 8-pin RJ45 connector that
supports RS232-C protocol.
The GigE fiber optic connection ports use duplex LC connectors.
The IEC connector ports accept a 3-lead IEC-320 connector for AC
power installations.
The terminal block connections accept a bare (tinned) wire for DC
power installations.
Singlemode (LX) Fiber Module
1330 nm
FP
-5.0 m to 10km
