Connector Specifications

Proprietary and Confidential
Acme Packet 1100 Hardware Installation Guide
Table 7 - 6. Acme Packet 1100 Environmental Specifications
Specification
Temperature
Relative Humidity
Maximum Altitude
Air Flow
Power Dissipation
Refer to the following table for information about the connector specifications for the
Acme Packet 1100.
Table 7 - 7. Acme Packet 1100 Connector Specifications
Specification
RJ45/Management Ethernet
Ports
RS232/Serial Port
IEC Connector Ports
Description
The Acme Packet 1100 is required to operate within the
temperature range of:
32° F to 104° F (+0° C to +40° C) (operating)
-4° F to 149° F (-20° C to +65° C) (storage)
10% to 85%, non-condensing
The Acme Packet 1100 System is required to operate below the
maximum altitude of 10,000 feet.
Single fan: 2.2 CFM (3.6 CFM Max)
Dual fans: 3.6 CFM (7.2 CFM Max)
10 Watts (maximum)
Description
The 3 x 8-pin RJ45 10/100 Ethernet ports are compliant with
IEEE's 802.3, 802.3u, 802.1q and 802.3ab.
The RS232 serial port uses an 8-pin RJ45 connector that supports
the RS232-C protocol.
The IEC connector ports accept a 3-lead IEC-320 connector for AC
power installations.
