MAINTENANCE
Media Ethernet Link
Alarms
Alarm Name
LINK UP ALARM
GIGPORT
LINK UP ALARM
GIGPORT
LINK DOWN
ALARM GIGPORT
LINK DOWN
ALARM GIGPORT
LINK UP ALARM
GIGPORT
LINK UP ALARM
GIGPORT
LINK DOWN
ALARM GIGPORT
LINK DOWN
ALARM GIGPORT
Management Ethernet
Link Alarms
Alarm Name
LINK UP ALARM
VXINTF
LINK UP ALARM
VXINTF
LINK UP ALARM
VXINTF
LINK DOWN ALARM
VXINTF
LINK DOWN ALARM
VXINTF
LINK DOWN ALARM
VXINTF
98 Acme Packet 4500 Hardware Installation Guide
The following table lists the NIU GigE interface link up/link down alarms.
Alarm
Alarm Severity Cause(s)
ID
131073 MINOR GigE S0P0 link up
131074 MINOR GigE S1P0 link up
131075 MAJOR GigE S0P0 link
down
131076 MAJOR GigE S1P0 link
down
131109 MINOR GigE S0P1 link up
131110 MINOR GigE S1P1 link up
131111 MAJOR GigE S0P1 link
down
131112 MAJOR GigE S1P1 link
down
The following table lists the NIU management Ethernet port alarms:
Alarm
Alarm Severity Cause(s)
ID
131077 MINOR Mgmt0 link up
131078 MINOR Mgmt1 link up
131079 MINOR Mgmt2 link up
131080 MAJOR Mgmt0 link down
131081 MAJOR Mgmt1 link down
131082 MAJOR Mgmt2 link down
Example Log
Graphic Display Message
Message
Slot 0 port 0 UP X LINK ALARMS (where X
is number of alarming
links)
Slot 1 port 0 UP X LINK ALARMS
Slot 0 port 0 DOWN X LINK ALARMS
Slot 1 port 0 DOWN X LINK ALARMS
Slot 0 port 1 UP X LINK ALARMS
Slot 1 port 1 UP X LINK ALARMS
Slot 0 port 1 DOWN X LINK ALARMS
Slot 1 port 1 DOWN X LINK ALARMS
Example Log
Graphic Display Message
Message
Port 0 UP X LINK ALARMS (where X
is number of alarming
links)
Port 1 UP X LINK ALARMS
Port 2 UP X LINK ALARMS
Port 0 DOWN X LINK ALARMS
Port 1 DOWN X LINK ALARMS
Port 2 DOWN X LINK ALARMS
