Environmental Specifications

Connector Specifications

Acme Packet 4600 Hardware Installation and Maintenance Guide
For the Acme Packet 4600 to function properly, Acme Packet recommends that
you follow the environmental guidelines in the following table.
Table 7 - 24. Acme Packet 4600 Environmental Specifications
Specification
Temperature The Acme Packet 4600 is required to operate within the temperature range
of:
0° C to +40° C, 32° F to 104° F (operating)
-20° C to +65° C, -4° F to 149° F (storage)
Relative Humidity Operating conditions of 10% to 85% humidity under non-condensing
operating conditions
Maximum Altitude The Acme Packet 4600 is required to operate below the maximum altitude
of 10,000 feet.
Air Flow 50 CFM front to back
Power Dissipation 250W typical 350W maximum (base system with 2 x 10GbE NIU)
Refer to the following table for information about the connector specifications
for the Acme Packet 4600.
Table 7 - 25. Acme Packet 4600 Connector Specifications
Specification
AC Connector Port
RJ45/Management Ethernet
Ports
RJ45/Alarm Contact Port
RS232/Serial Port
1 GbE/10GbE Port(s)
Terminal Block Connections
Description
Description
The IEC lead connector port on each power supply accepts a 3-
lead IEC-60320 C14 connector for AC power installations (2).
The 3 x 8-pin RJ45 10/100/1000BaseT ports are compliant with
IEEE's 802.3, 802.3u, and 802.3ab.
Any alarms generated by the system are accessible via the 8-pin
RJ45 alarm contact port.
The RS232 serial port uses an 8-pin RJ45 connector that supports
RS232 protocol.
The four 1 GbE fiber optic connection ports (P0-P3) and the two
10GbE fiber optic connection ports (P4-P5) use duplex LC connec-
tors (2).
The terminal block connections accept a bare (tinned) wire for DC
power installations on each DC power supply (2).
