MAINTENANCE
SFP Identification
90 Acme Packet 4500 Hardware Installation Guide
The following images show the multi mode and single mode SFP transceivers used
in the Net-Net 4500 NIU 4500 cards.
Black latch means the SFP is a multi
mode transceiver. SX 850 nm 550 m
multi-mode label is on the back.It uses
an orange colored fiber optic cable.
Blue latch means the SFP is a single-
mode transceiver. LX 1310 nm 10 km
single-mode label is on the back. It
uses a yellow colored fiber optic cable.
Version 1.0
