Introduction

Physical Specifications

Acme Packet 4500
Chassis's

Specifications

AC Power Supply
Physical
Dimensions
DC Power Supply
Physical
Dimensions
Version 1.0
This chapter provides information regarding the physical, electrical, environmental,
and connector specifications of the Acme Packet 4500. It also lists regulatory
specifications and certifications.
This table lists the Net-Net 4500's physical dimensions and weight.
Specification Description
Height 1.72" (4.37 cm) (1U)
Width 17.10" (43.43 cm) (+ mounting ear width:
19" (48.26 cm))
Depth 19" (48.26 cm) (+ mounting slide bar
depth)
Weight approximately 19 lbs (8.62 kg), fully
loaded
This table lists the Net-Net 4500's AC power supply's physical dimensions and
weight.
Specification
Height
Width
Depth
Weight
This table lists the Net-Net 4500's DC power supply's physical dimensions and
weight.
Specification
Height
Width
Depth
Weight
Specifications
Description
1.594" (4.05 cm)
4" (10.16 cm)
8.50" (21.59 cm)
2lbs., 2 oz. (0.96 kg)
Description
1.594" (4.05 cm)
4" (10.16 cm)
8.50" (21.59 cm)
2lbs., 0 oz. (0.91 kg)
