Voltage Alarms
Alarm
PLD VOLTAGE
ALARM 2P5V
(2.5 Volt Rail)
PLD VOLTAGE
ALARM 3P3V
(3.3 Volt Rail)
PLD VOLTAGE
ALARM 5V
(5 Volt Rail)
PLD VOLTAGE
ALARM CPU
(Host Voltage)
NIU Card Alarms
Alarm
PHY0 Removed
PHY0 Inserted
PHY1 Removed
PHY1 Inserted
Link and SDP
Alarms
Version 1.0
The following table lists the voltage alarms.
Alarm ID Alarm Severity
65544 MINOR
EMERGENCY
65545 MINOR
EMERGENCY
65546 MINOR
EMERGENCY
65547 MINOR
EMERGENCY
The following table lists the NIU card alarms. PHY0 and PHY1 are both located on
the same NIU. PHY0 encompasses S0P0 and S0P1, while PHY1 encompasses S1P0
and S1P1. Therefore, both insertion and both removal alarms will be activated at the
same time when the NIU is inserted or removed from the Acme Packet 4500.
Alarm ID Alarm Severity
65550 MAJOR
65552 MAJOR
65553 MAJOR
65554 MAJOR
Link alarms are generated when a network cable is plugged into or unplugged from
a configured network interface. For each possible network interface, an alarm exists
that indicates whether the link goes up or down.
The following tables list detailed information about the Acme Packet 4500's NIU link
alarms, including their ID assignments, severities, causes, log messages, and
messages printed in the graphic display window.
Cause(s) Log Message
• Voltage 2.5V CPU has minor alarm
• Voltage 2.5V CPU has emergency
alarm, the system should
shutdown
• Voltage 3.3V has minor alarm
• Voltage 3.3V has emergency
alarm, the system should
shutdown
• Voltage 5V has minor alarm
• Voltage 5V has emergency alarm,
the system should shutdown
• Voltage CPU has minor alarm
• Voltage CPU has emergency alarm,
the system should shutdown
Cause(s) Log Message
NIU S0Px was physical interface
removed card 0 has been
removed
NIU S0Px was None
inserted
NIU S1Px was physical interface
removed card 1 has been
removed
NIU S1Px was None
inserted
Acme Packet 4500 Hardware Installation Guide 97
MAINTENANCE
Graphic Display
Window
Message
Graphic Display
Window Message
