Caution
Removing an Optical
Transceiver
Version 1.0
Copper catagory 5 or 6 ethernet cable
To prevent damage to the optical lens, We recommend that
the protective dust cover stay on the optical transceiver port
when the GigE physical interface card is not cabled.
To remove the optical transceiver on an NIU's SFP port:
1.
Unplug all GigE fiber optic cables from the optical transceiver to be replaced.
bale clasps in rest position
Acme Packet 4500 Hardware Installation Guide 93
MAINTENANCE
