C External Connections
.
Sample manager event-out/event-in connections:
Signal connections
Inject Start Out
Inject Hold In

Connecting to the electricity source

Each system module requires a separate, grounded power source. The ground
connection in all power outlets must be common and physically close to the
system.
Warning:
• Use only authorized power cords that are shipped with your
instrument or supplied from your local Water's distributor.
• Power-off and unplug each system module before performing any
maintenance operation on the module.
• Connect each system module to a common ground.
To connect to the electricity source:
Recommendation:
(UPS) for optimum, long-term, input voltage stability. For sizing and selection
of the UPS or line conditioner, contact Waters technical support.
1. Connect the female end of the power cord to the receptacle on the rear
panel of each module.
2. Connect the male end of the power cord to a suitable wall outlet.
Alternative:
female end of the FlexCart's electrical cables (included in the startup
kit) to the receptacle on the rear panel of each system module. Connect
the hooded, male end of the FlexCart's electrical cables to the power
strips on the back of the cart. Finally, connect each power strip's cable to
a wall outlet operating on its own circuit.
78 July 7, 2014, 715003736IVD Rev. C
Description
Indicates (with a contact closure output) that an
injection has started.
Delays the next injection when the sample manager
receives a contact closure input (from another
system module, for example).
To avoid electrical shock, do as follows:
Use a line conditioner and uninterruptible power supply
If your system includes the optional FlexCart, connect the
