3 Preparing the System
The following table describes the items in the binary solvent manager control
panel:
Binary solvent manager control panel items:
Control panel item
Flow LED
Status
System Pressure
Flow Rate
Solvent Composition
(Stop Flow)
You can access these additional functions by right-clicking anywhere in the
binary solvent manager control panel:
34 July 7, 2014, 715003736IVD Rev. C
Description
Displays the actual flow LED on the front
panel of the binary solvent manager unless
communications with the binary solvent
manager are lost.
Displays the status of the current operation.
Displays system pressure, in kPa, bar, or psi.
You can customize pressure units via the
ACQUITY UPLC Console.
Displays the total flow rate of the binary
solvent manager, from 0.000 to 2.000 mL/min
under normal operation and 0.000 to 8.000
mL/min when priming.
Displays the percentage of solvent to be
drawn from the solvent lines (A and B).
Composition values range from 0.0 to
100.0%.
Immediately stops all flow from the binary
solvent manager.
