Sample manager control panel items: (Continued)
Control panel item
Current Column Heater
Temperature
Column Heater Set Point
(Display Console)
You can access these additional functions by right-clicking anywhere in the
sample manager control panel.
Additional functions in the sample manager control panel:
Control panel function
Prime
Wash needle
Reset SM
Help
Description
Displays the current column heater
temperature to 0.1 °C resolution, even when
active temperature control is disabled.
Displays the current column heater set point,
to 0.1 °C resolution. When active
temperature control is disabled, this field
displays "Off".
Displays the ACQUITY UPLC Console.
Description
Displays the Prime dialog box.
See "Priming the SM-FTN" in the Sample
Manager - Flow Through Needle Operator's
Overview and Maintenance Guide, (part
number 715003737IVD)
Displays the Wash Needle dialog box.
See "Washing the SM-FTN needle" in the
Sample Manager - Flow Through Needle
Operator's Overview and Maintenance Guide,
(part number 715003737IVD)
Resets the sample manager following an
error condition.
Displays the ACQUITY UPLC Console
online Help.
