Signal connections
Connecting signal cables
Refer to the signal connection location shown on the silk-screened label affixed
to the rear panel of each system module.
Required materials
•
9/32-inch nut driver
•
Flat-blade screwdriver
•
Connector
•
Signal cable
To connect signal cables:
1.
Insert the connector into the connector port on the back of the system
module.
Connector port
Connector
July 7, 2014, 715003736IVD Rev. C
Signal connections
73
