TQ-S mass spectrometer

The following table lists the physical specifications for the Xevo TQ-S mass
spectrometer:
CH-A physical specifications:
Attribute
Height
Width
Length
Weight, with two scroll
pumps
Weight, with two
rotary pumps

Environmental specifications

The following table lists the environmental specifications for the ACQUITY
UPLC I-Class IVD system:
Warning:
outside the operating temperature and humidity specified.
ACQUITY UPLC I-Class IVD system environmental specifications:
Attribute
Acoustic noise
Operating temperature
Operating humidity
Shipping and storage temperature
Shipping and storage humidity
Specification
71.1 cm (28 inches)
61.0 cm (24 inches)
99.5 cm (39 inches)
352 kg (777 pounds)
408 kg (899 pounds)
To prevent inaccurate results, do not operate the instrument
Environmental specifications
Specification
<65 dBA, system: binary solvent
manager, sample manager
(SM-FTN), CH-A
15 to 28°C (59 to 82 °F)
Short-term (1.5 h) variations
must be no more than ±2 °C
(3.5 °F)
20 to 80%, noncondensing
0 to 40 °C
20 to 80%, noncondensing
July 7, 2014, 715003736IVD Rev. C 63
