Product Specifications

The Modbus TCP/IP Client/Server Enhanced Communication Module with
Reduced Data Block allows Rockwell Automation
interface easily with Modbus TCP/IP-compatible devices, such as Modicon
Programmable Automation Controllers (PACs) and a wide variety of Modbus
TCP/IP-compatible instruments and devices.
The MVI56E-MNETR uses a reduced Input/Output (I/O) data image block size for
transferring data between itself and a ControlLogix processor. This makes it ideal
for remote rack applications using ControlNet™ or EtherNet/IP™ process
networks. The module also works well for applications that require redundant
ControlLogix processors.
MVI56E-MNETR enhancements include local and remote configuration and
diagnostics through the module's Ethernet port, CIPconnect
bridging though Rockwell Automation ControlNet and EtherNet/IP networks, and
an on-board web server for access to module documentation and sample
program files.

5.1.1 General Specifications

Reduced I/O image size designed specifically to optimize remote
rack implementations
Backward compatible with previous MVI56-MNETR versions
Single-slot 1756 ControlLogix backplane compatible
10/100 Mbps auto crossover detection Ethernet configuration and application
port
User-definable module data memory mapping of up to 5000 16-bit registers
CIPconnect-enabled network configuration and diagnostics monitoring using
ControlLogix 1756-ENxT and 1756-CNB modules and EtherNet/IP pass-
through communication
ProSoft Configuration Builder (PCB) software supported, a Windows-based
graphical user interface providing simple product and network configuration
Sample ladder logic and Add-On Instructions (AOI) are used for data transfer
between module and processor
Internal web server provides access to product documentation, module
status, diagnostics, and firmware updates
4-character, alpha-numeric, scrolling LED display of status and diagnostics
data in plain English – no cryptic error or alarm codes to decipher
ProSoft Discovery Service (PDS) software used to locate the module on the
network and assign temporary IP address
Personality Module - a non-volatile, industrial-grade Compact Flash (CF) card
used to store network and module configuration, allowing quick in-the-field
product replacement by transferring the CF card
