Start Here
User Manual
Fill in the module properties as follows:
3
Parameter
Name
Description
Comm Format
Slot
Input Assembly Instance
Input Size
Output Assembly Instance
Output Size
Configuration Assembly
Instance
Configuration Size
4 Click OK to confirm. The new module is now visible:
Expand the Tasks folder, and then expand the MainTask folder.
5
6 On the MainProgram folder, click the right mouse button to open a shortcut
menu. On the shortcut menu, choose N
In the New Routine dialog box, enter the name and description of your
7
routine, and then click OK.
Page 40 of 175
Modbus TCP/IP Interface Module with Reduced Data Block
Value
Enter a module identification string. Example: MNETR_2
Enter a description for the module. Example: Modbus TCP/IP
Interface Module with Reduced Data Block
Select DATA-INT
Enter the slot number in the rack where the MVI56E-MNETR module
is located.
1
42
2
42
4
0
EW
MVI56E-MNETR ♦ ControlLogix Platform
R .
OUTINE
ProSoft Technology, Inc.
June 14, 2011
