Battery Life Advisory

Note: Modules manufactured after April 1
date the following applies:
The module uses a rechargeable Lithium Vanadium Pentoxide battery to back up the real-time clock and CMOS
settings. The battery itself should last for the life of the module. However, if left in an unpowered state for 14 to 21
days, the battery may become fully discharged and require recharging by being placed in a powered-up ControlLogix
chassis. The time required to fully recharge the battery may be as long as 24 hours.
Once it is fully charged, the battery provides backup power for the CMOS setup and the real-time clock for
approximately 21 days. Before you remove a module from its power source, ensure that the battery within the module
is fully charged (the BATT LED on the front of the module goes OFF when the battery is fully charged). If the battery
is allowed to become fully discharged, the module will revert to the default BIOS and clock settings.
Note: The battery is not user-replaceable or serviceable.
Important Safety Information
North America Warnings
Warning - Explosion Hazard - Substitution of components may impair suitability for Class I, Division 2.
A
Warning - Explosion Hazard - When in Hazardous Locations, turn off power before replacing or rewiring
B
modules.
Warning - Explosion Hazard - Do not disconnect equipment unless power has been switched off or the area is
C
known to be nonhazardous.
Suitable for use in Class I, Division 2 Groups A, B, C, and D, Hazardous Locations or Non-Hazardous Locations.
D
ATEX/IECEx Warnings and Conditions of Safe Usage:
Power, Input, and Output (I/O) wiring must be in accordance with the authority having jurisdiction
Warning - Explosion Hazard - When in hazardous locations, turn off power before replacing or wiring modules.
A
Warning - Explosion Hazard - Do not disconnect equipment unless power has been switched off or the area is
B
known to be non-hazardous.
C These products are intended to be mounted in an ATEX/IECEx Certified, tool-secured, IP54 enclosure. The devices
shall provide external means to prevent the rated voltage being exceeded by transient disturbances of more than
40%. This device must be used only with ATEX certified backplanes.
D
Before operating the reset switch, be sure the area is known to be non-hazardous.
Electrical Ratings
Backplane Current Load: 800 mA @ 5 Vdc; 3 mA @ 24 Vdc
Operating Temperature: 0° C to 60° C (32° F to 140° F)
Storage Temperature: -40° C to 85° C (-40° F to 185° F)
Shock: 30 g operational; 50 g non-operational; Vibration: 5 g from 10 Hz to 150 Hz
Relative Humidity 5% to 95% (without condensation)
All phase conductor sizes must be at least 1.3 mm (squared) and all earth ground conductors must be at least
4mm (squared).
st , 2011 do not contain a battery. For modules manufactured before that
