Diagnostics and Troubleshooting
User Manual

4.4.1 Backplane Status

Use the Status menu to view current backplane status, including
Number of retries
Backplane status
Fail count
Number of words read
Number of words written
Number of words parsed
Error count
Event count
Command count
During normal operation, the read, write, and parsing values should increment
continuously, while the error value should not increment.
The status values on this menu correspond with the members of the MVI56E-
MNETR Status object (page 131).
