MVI56E-MNETR ♦ ControlLogix Platform
Modbus TCP/IP Interface Module with Reduced Data Block
4.7

Monitoring MNET Server Information

Use the MNET SERVER menu to view the configuration and status information
for the MNET server.

4.7.1 Config

Use the Configuration menu to view configuration settings for MNET servers
connected to the MNET Client.
The information on this menu corresponds with the configuration information in
the MNET Servers settings in ProSoft Configuration Builder (page 65).

4.7.2 Status

Use the Status menu to view the status of each MNET server connected to the
MNET Client 0. During normal operation, the number of requests and responses
should increment, while the number of errors should not change.
