Ladder Logic
User Manual
3.1.2 MNETRSTATUS
This object views the status of the module. The MNETRSTATUS object shown
below is updated each time a read block is received by the processor. Use this
data to monitor the state of the module at a "real-time rate".
The following table describes the structure of this object.
Name
PassCnt
ProductVersion
ProductCode
BlockStats
Reserved1
Reserved2
MNETReq
MNETResp
MBAPReq
MBAPResp
ClientStatus
MNETRBLOCKSTATS
This status object contains a structure that includes the status information for the
data transfer operations between the processor and the module
(MNETRBLOCKSTATS). The following table describes the structure of this
object.
Name
Read
Write
Parse
Event
Cmd
Err
Page 82 of 175
Modbus TCP/IP Interface Module with Reduced Data Block
Data Type
Description
INT
Program cycle counter
INT
Shows the module software version
INT[2]
This identifies the module product code
MNETRBLOCKSTATS
Status information for the data transfer
(page 82)
operations between the processor and the
module
INT
Reserved for future use
INT
Reserved for future use
INT
The number of MNET (Port 2000) requests
received
INT
The number of MNET (Port 2000) responses
sent
INT
The number of MBAP (Port 502) requests
received
INT
The number of MBAP (Port 502) responses
sent
MNETRCLIENTSTATS
Client Status Data
(page 83)
Data Type
Description
INT
Total number of read block transfers
INT
Total number of write block transfers
INT
Total number of blocks parsed
INT
Total number of event blocks received
INT
Total number of command blocks received
INT
Total number of block transfer errors
MVI56E-MNETR ♦ ControlLogix Platform
ProSoft Technology, Inc.
June 14, 2011
