MVI56E-MNETR ♦ ControlLogix Platform
Modbus TCP/IP Interface Module with Reduced Data Block
1.8

Setting Temporary IP Address

Important: ProSoft Configuration Builder locates MVI56E-MNETR modules through UDP
broadcast messages. These messages may be blocked by routers or layer 3 switches. In that
case, ProSoft Discovery Service will be unable to locate the modules.
To use ProSoft Configuration Builder, arrange the Ethernet connection so that there is no router/
layer 3 switch between the computer and the module OR reconfigure the router/layer 3 switch to
allow routing of the UDP broadcast messages.
1 Click the S
T
ECHNOLOGY
2 Click to start P
If you have used other Windows configuration tools before, you will find the
screen layout familiar. PCB's window consists of a tree view on the left, and
an information pane and a configuration pane on the right side of the window.
When you first start PCB, the tree view consists of folders for Default Project
and Default Location, with a Default Module in the Default Location folder.
The following illustration shows the PCB window with a new project.
3 Use the mouse to select D
right mouse button to open a shortcut menu.
ProSoft Technology, Inc.
June 14, 2011
button, and then navigate to P
TART
.
S C
RO OFT ONFIGURATION
EFAULT
ROGRAMS
B .
UILDER
M in the tree view, and then click the
ODULE
Start Here
User Manual
/ P S
RO OFT
Page 19 of 175
