Start Here - ProSoft Technology ControlLogix inRAx MVI56E-MNETR User Manual

MVI56E-MNETR ♦ ControlLogix Platform
Modbus TCP/IP Interface Module with Reduced Data Block
1

Start Here

In This Chapter
What's New? ......................................................................................... 12
System Requirements ........................................................................... 13
Package Contents ................................................................................. 14
Setting Jumpers .................................................................................... 15
Installing the Module in the Rack ........................................................... 16
Installing the Configuration Tools .......................................................... 17
Connecting Your PC to the Module ....................................................... 18
Setting Temporary IP Address .............................................................. 19
Connecting to the Module's Web Page ................................................. 26
Uploading the Add-On Instruction from the Module ............................... 27
Creating a New RSLogix 5000 Project .................................................. 27
To get the most benefit from this User Manual, you should have the following
skills:
Rockwell Automation
ladder logic, and transfer the ladder logic to the processor
Microsoft Windows: install and launch programs, execute menu commands,
navigate dialog boxes, and enter data
Hardware installation and wiring: install the module, and safely connect
Modbus TCP/IP and ControlLogix devices to a power source and to the
MVI56E-MNETR module's application port(s)
ProSoft Technology, Inc.
June 14, 2011
®
RSLogix™ software: launch the program, configure
Start Here
User Manual
Page 11 of 175
