MVI56E-MNETR ♦ ControlLogix Platform
Modbus TCP/IP Interface Module with Reduced Data Block
4

Diagnostics and Troubleshooting

In This Chapter
Reading Status Data from the Module .................................................. 92
The Diagnostics Menu ........................................................................... 93
Monitoring Module Information .............................................................. 97
Monitoring Backplane Information ......................................................... 97
Monitoring Database Information .......................................................... 99
Monitoring MNET Client Information ................................................... 100
Monitoring MNET Server Information .................................................. 101
LED Status Indicators .......................................................................... 102
Client Configuration Error Word .......................................................... 105
Clearing a Fault Condition ................................................................... 106
Troubleshooting ................................................................................... 107
The module provides information on diagnostics and troubleshooting in the
following forms:
LED status indicators on the front of the module provide information on the
module's status.
Status data contained in the module can be viewed in ProSoft Configuration
Builder through the Ethernet port.
Status data values are transferred from the module to the processor.
