The MVI56 Phantom Network Protocol Master Communication Module allows
ControlLogix I/O compatible processors to easily interface with Phantom metal
detector devices.

5.1.1 Features and Benefits

The MVI56-PNPM module acts as a gateway between the Phantom network and
the ControlLogix processor. The data transfer from the ControlLogix processor is
asynchronous from the actions on the Phantom network. A 5000-word register
space in the module is used to exchange data between the processor and the
Phantom network.

5.1.2 General Specifications

Single Slot - 1756 backplane compatible
Local or remote rack
The module is recognized as an Input/Output module and has access to
processor memory for data transfer between processor and module
Ladder Logic is used for data transfer between module and processor.
Configuration data obtained through user-defined ladder. Sample ladder file
included
