Ladder Logic
User Manual

3.1.3 MNETRCONTROL

Contains the data structure required for the processor to request special tasks
from the module. The command control task allows the processor to dynamically
enable commands configured in the port command list. The event command task
allows the processor to dynamically build any commands to be sent by the MNET
Client to a remote Server.
The following table describes the structure of this object.
Name
BootTimer
WarmBoot
ColdBoot
EventCmdTrigger
EventCmd
CmdControl
PassThru
IPAddress
MNETREVENTCMD
The MNETREVENTCMD structure holds the information required for an event
command. An array of this object should be defined and should hold the event
command set to be employed in the application. The following table describes
the structure of this object.
Name
IP0
IP1
IP2
IP3
ServPort
Node
DBAddress
Count
Swap
Function
Address
Result
Page 84 of 175
Modbus TCP/IP Interface Module with Reduced Data Block
Data Type
TIMER
BOOL
BOOL
BOOL
MNETREVENTCMD (page
84)
MNETRCMDCONTROL
(page 85)
MNETRPASSTHRU (page
86)
MNETIPADDRESS (page
86)
Data Type
INT
INT
INT
INT
INT
INT
INT
INT
INT
INT
INT
INT
MVI56E-MNETR ♦ ControlLogix Platform
Description
Timer to clear warmboot and coldboot
Triggers a Cold Boot Command
Triggers a Warm Boot Command
Triggers the Event Command.
This object contains the attributes to define a
Master command. An array of these objects is
used for each port.
Controls the execution of the commands listed
in the configuration under the [MNET Client 0
Commands] section.
Transfers a remote Client's commands
through the MNETR Module straight into the
Processor's Controller tags.
Getting and Setting IP address to and from
Module
Description
First digit of IP address
Second digit of IP address
Third digit of IP address
Last digit of IP address
TCP Service Port number (0-65535), 502 for
MBAP, 2000 for MNET
Modbus slave node address (0 to 247)
Module internal database for message
Register or data point count
Swap code for functions 3 and 4
Modbus function code for message
Address to interface with in device
Shows the result of the event that was sent
