MVI56E-MNETR ♦ ControlLogix Platform
Modbus TCP/IP Interface Module with Reduced Data Block
Block 9990: Set Module IP Address
IP Set Request (Write Block)
Offset
0
1
2
3
4
5 to 41
IP Set Response (Read Block)
Offset
0
1
2
3
4
5
6 to 41
Block 9991: Get Module IP Address
IP Get Request (Write Block)
Offset
0
1 to 41
IP Get Response (Read Block)
Offset
0
1
2
3
4
5
6 to 41
ProSoft Technology, Inc.
June 14, 2011
Description
9990
First digit of dotted IP address
Second digit of dotted IP address
Third digit of dotted IP address
Last digit of dotted IP address
Reserved
Description
0
Write Block ID
First digit of dotted IP address
Second digit of dotted IP address
Third digit of dotted IP address
Last digit of dotted IP address
Spare data area
Description
9991
Spare data area
Description
0
Write Block ID
First digit of dotted IP address
Second digit of dotted IP address
Third digit of dotted IP address
Last digit of dotted IP address
Spare data area
Reference
User Manual
Length
1
1
1
1
1
36
Length
1
1
1
1
1
1
35
Length
1
40
Length
1
1
1
1
1
1
35
