Start Here
User Manual
Select the 1756-M
2
This action opens the N
3 Set the Module Properties values as follows:
Parameter
Name
Description
Comm Format
Slot
Input Assembly Instance
Input Size
Output Assembly Instance
Output Size
Configuration Assembly Instance 4
Configuration Size
Page 34 of 175
Modbus TCP/IP Interface Module with Reduced Data Block
(G 1756 M
ODULE ENERIC
dialog box.
M
EW ODULE
Value
Enter a module identification string. The recommended value is
MNETR.
Enter a description for the module. Example: Modbus TCP/IP
Interface Module with Reduced Data Block.
Select D
-INT (Very Important)
ATA
Enter the slot number in the rack where the MVI56E-MNETR
module is to be installed.
1
42
2
42
0
MVI56E-MNETR ♦ ControlLogix Platform
) from the list and click OK.
ODULE
