Ladder Logic
User Manual
3.1

MNETRMODULEDEF

All data related to the MVI56E-MNETR is stored in a user defined data type. An
instance of the data type is required before the module can be used. This is done
by declaring a variable of the data type in the C
dialog box.
The following table describes the structure of the object.
Name
DATA
STATUS
CONTROL
UTIL
This object contains objects that define the configuration, user data, status and
command control data related to the module. Each of these object types is
discussed in the following topics of the document.
Page 80 of 175
Modbus TCP/IP Interface Module with Reduced Data Block
Data Type Description
MNETRDATA (page These objects hold data to be transferred
81)
between the processor and the MVI56E-
MNETR module
MNETRSTATUS This object views the status of the module.
(page 82)
MNETRCONTROL This object contains the data structure required
(page 84) for the processor to request special tasks from
the module
MNETRUTIL (page This data object stores the variables required
87) for the data transfer between the processor
and the module.
