5 Reference

5.1 Product Specifications

The MVI56E-SMGC Enhanced SM General Communication Module allows ControlLogix
I/O compatible processors to interface easily with SM General Communication Protocol
devices over an Ethernet network.
The MVI56E-SMGC module interfaces an Ethernet communication device using the SM
General Communication Protocol with the ControlLogix processor. A single client is
present in the module to interface with a single server. The client permits both the
reception and transmission of data between the ControlLogix processor and attached
device.

5.1.1 Hardware Specifications

Specification
Dimensions
Backplane current load
Operating temperature
Storage temperature
Shock
Vibration
Relative humidity
LED indicators
4-character, scrolling,
alphanumeric LED display
Ethernet port
ProSoft Technology, Inc.
Description
Standard 1756 ControlLogix
800 mA @ 5 VDC
3 mA @ 24 VDC
0°C to 60°C (32°F to 140°F)
-40°C to 85°C (-40°F to 185°F)
30 g operational
50 g non-operational
5 g from 10 to 150 Hz
5% to 95% (with no condensation)
Battery Status (ERR)
Application Status (APP)
Module Status (OK)
Shows module, version, IP, application port setting, port
status, and error information
10/100 Base-T, RJ45 Connector, for CAT5 cable
Link and Activity LED indicators
Auto-crossover cable detection
®
single-slot module
