5.1.2 Functional Specifications

The MVI56E-MNETR transfers data in small I/O blocks than the MVI56E-
MNET, which makes it ideal for installations in remote racks or where
bandwidth is limited.
Works well with redundant ControlLogix Programmable Automation
Controllers (PACs) using ControlNet.
Module appears to the ControlLogix processor as an input/output (I/O)
module
40-word scheduled I/O image blocks used for data transfers require
significantly less bandwidth than the MVI56E-MNET
Retrieving module status and executing special functions (command control,
event commands, etc.) are supported in ladder logic by special block transfer
codes

5.1.3 Hardware Specifications

Specification
Backplane Current Load
Operating Temperature
Storage Temperature
Shock
Relative Humidity
LED Indicators
4-Character, Scrolling, Alpha-
Numeric LED Display
Debug/Configuration/Application Ethernet port (E1)
Ethernet Port
Shipped with Unit
ProSoft Technology, Inc.
June 14, 2011
Description
800 mA @ 5 Vdc
3 mA @ 24 Vdc
0° C to 60° C (32° F to 140° F)
-40° C to 85° C (-40° F to 185° F)
30 g operational
50 g non-operational
Vibration: 5 g from 10 to 150 Hz
5% to 95% (without condensation)
Battery Status (ERR)
Application Status (APP)
Module Status (OK)
Shows Module, Version, IP, Application Port
Setting, Port Status, and Error Information
10/100 Base-T, RJ45 Connector, for CAT5 cable
Link and Activity LED indicators
Auto-crossover cable detection
5-foot Ethernet straight-through cable
