MVI56E-MNETR ♦ ControlLogix Platform
Modbus TCP/IP Interface Module with Reduced Data Block
Standard Modbus Exception Code Errors
Code
1
2
3
4
5
6
Module Communication Error Codes
Code
-2
-11
253
254
255
MNET Client Specific Errors
Code
-33
-36
-37
Command List Entry Errors
Code
-40
-41
-42
-43
-44
-45
-46
-47
-48
Note: When the Client gets error -47 or -48, it uses the adjustable ARP Timeout parameter in the
configuration file to set an amount of time to wait before trying again to connect to this non-existent
server. This feature allows the Client to continue sending commands and polling other existing
servers, while waiting for the non-existent server to appear on the network.
ProSoft Technology, Inc.
June 14, 2011
Description
Illegal function
Illegal data address
Illegal data value
Failure in associated device
Acknowledge
Busy; message was rejected
Description
Timeout while transmitting message
Timeout waiting for response after request
Incorrect slave/server address in response
Incorrect function code in response
Invalid CRC/LRC value in response
Description
Failed to connect to server specified in command
MNET command response timeout
TCP/IP connection ended before session finished
Description
Too few parameters
Invalid enable code
Internal address > maximum address
Invalid node address (<0 or >255)
Count parameter set to 0
Invalid function code
Invalid swap code
ARP could not resolve MAC from IP (bad IP address, not part of a
network, invalid parameter to ARP routine).
Error during ARP operation: the response to the ARP request did
not arrive to the module after a user-adjustable ARP Timeout.
Reference
User Manual
Page 129 of 175
