Enable
N (0), Y (1), or C
O ES
This field defines whether the command is to be executed and under what
conditions.
Value
N (0)
O
(1)
Y
ES
C (2) The command will execute only if the internal data associated with the
ONDITIONAL
Internal Address
0 to 4999 (for word-level addressing)
or
0 to 65535 (for bit-level addressing)
This field specifies the database address in the module's internal database to use
as the destination for data brought in by a read command or as the source for
data to be sent out by a write command. The database address is interpreted as
a bit address or a 16-bit word (register) address, depending on the Modbus
Function Code used in the command.
For Modbus functions 1, 2, 5, and 15, this parameter is interpreted as a bit-
level address.
For Modbus functions 3, 4, 6, and 16, this parameter is interpreted as a word-
or register-level address.
Poll Interval
0 to 65535
This parameter specifies the minimum interval to execute continuous commands
(Enable code of 1). The parameter is entered in tenths of a second. Therefore, if
a value of 100 is entered for a command, the command executes no more
frequently than every 10 seconds.
ProSoft Technology, Inc.
June 14, 2011
(2)
ONDITIONAL
Description
The command is disabled and will not be executed in the normal polling
sequence.
The command is executed each scan of the command list if the Poll Interval
time is set to zero. If the Poll Interval time is set to a nonzero value, the
command will be executed when the interval timer expires.
command changes. This value is valid only for write commands.
