Client Configuration Error Word

If a configuration error is found for the Client, the Client Configuration Error Word
will have a value other than zero. The Configuration Error Word is a controller tag
in MNET.STATUS.ClientStats in the ladder logic.
The bits in the Configuration Error Word have the following definitions:
Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Correct any invalid data in the configuration for proper module operation. When
the configuration contains a valid parameter set, all the bits in the configuration
word will be clear. This does not indicate that the configuration is valid for the
user application. Make sure each parameter is set correctly for the specific
application.
