5.8.2 Choosing the Controller Type

The sample application is for a 1756-L63 ControlLogix 5563 Controller. If you are
using a different model of the ControlLogix processor, you must configure the
sample program to use the correct processor model.
In the Controller Organization list, select the folder for the controller and then
1
click the right mouse button to open a shortcut menu.
2 On the shortcut menu, choose P
Properties dialog box.
3 Click the C
the Change Controller dialog box.
Open the T
4
Select the correct firmware revision for your controller, if necessary.
5
6 Click OK to save your changes and return to the previous window.
