Ladder Logic
User Manual
MNETRINITOUTDATA
Used to bring the Module into a known state after a restart operation.
Name
TriggerInitOut
InitializeOutputData
RetInitOutData
TriggerInitOutPending
RetInitOutDataBlkID
InitOutBlkIDLim
Page 88 of 175
Modbus TCP/IP Interface Module with Reduced Data Block
Data Type
BOOL
INT
INT[200]
BOOL
INT
INT
MVI56E-MNETR ♦ ControlLogix Platform
Description
Trigger Output Data Initialization.
Quantity of Blocks(200 words of "ReadData")
for the module to read from the PLC. [0 to 24]
means a qty of 1 to 25
Returned Initialization output data
Set after the ladder has sent an event cmd to
the module and is waiting for the status to be
returned
Returned Block ID for Returned Initialize
Output Data command.
Block Index Limit for ReadData size of the
array
