1.8.1 Using CIPconnect to Connect to the Module

You can use CIPconnect
Ethernet using Rockwell Automation's 1756-ENBT EtherNet/IP
allows you to configure the MVI56E-MNETR module and network, upload and
download files, and view network and module diagnostics from a PC. RSLinx is
not required when you use CIPconnect. All you need are:
The IP addresses and slot numbers of any 1756-ENBT modules in the path
The ControlNet node numbers and slot numbers of any 1756-CNBx
ControlNet Bridge modules in the path
The slot number of the MVI56E-MNETR in the destination ControlLogix
chassis (the last ENBT/CNBx and chassis in the path).
To use CIPconnect, follow these steps.
1 In the Select Connection Type dropdown list, choose 1756-ENBT. The
default path appears in the text box, as shown in the following illustration.
Page 24 of 175
Modbus TCP/IP Interface Module with Reduced Data Block
®
to connect a PC to the MVI56E-MNETR module over
MVI56E-MNETR ♦ ControlLogix Platform
®
module. This
ProSoft Technology, Inc.
June 14, 2011
