Diagnostics and Troubleshooting
User Manual
4.1

Reading Status Data from the Module

The MVI56E-MNETR module returns a Status Data block that can be used to
determine the module's operating status. This data is located in the module's
database at a location specified by the Error Status Pointer configuration
parameter. This data is transferred to the ControlLogix processor continuously.
The Configuration/Debug port provides the following functionality:
Full view of the module's configuration data
View of the module's status data
Complete display of the module's internal database (registers 0 to 4999)
Version Information
Control over the module (warm boot, cold boot, transfer configuration)
Facility to upload and download the module's configuration file
